Model Number:
LKF-FS40
Document:
The LKF-FS40L1 silicon photonic gyroscope breaks through traditional FOG design with a silicon photonic integrated optical circuit. It is an ideal medium-low precision angular rate sensor for navigation and control, widely used in inertial measurement applications. Based on proven designs with engineering optimizations for mass production, it delivers exceptional cost performance. Featuring compact size, light weight, low power consumption, and a simple interface, it offers significant advantages across navigation and control fields.
LKF-FS40L1 Single-Axis Silicon Photonic Gyroscope Performance Parameters
| Parameter | A | B | C |
|---|---|---|---|
| Bias Stability (°/h ,1σ, 10s) | ≤0.8 | ≤0.6 | ≤0.3 |
| Bias Repeatability (°/h ,1σ) | ≤0.8 | ≤0.6 | ≤0.3 |
| Random Walk Coefficient (°/√h) | ≤0.1 | ≤0.08 | ≤0.03 |
| Scale Factor Non-linearity (ppm ,1σ) | ≤200 | ≤100 | ≤50 |
| Scale Factor Repeatability (ppm ,1σ) | ≤200 | ≤100 | ≤50 |
| Dynamic Range (°/s) | ±500 | ||
| Magnetic Field Sensitivity (°/hr/Gs) | ≤0.05 | ||
| Operating Temperature (℃) | -40 ～ +65 | ||
| Storage Temperature (℃) | -50 ～ +70 | ||
| Vibration Condition (g, Hz) | 4.2, 20 ～ 2000 | ||
| Weight (g) | 65±5 | ||
| Dimensions (mm) | 40*40*17 | ||
